PCD800B.1545.75
Industrial
15.87mm Dia, PCD, Spiral Router Cutter, Z10+1, RH, 15.87mm Shank, 105mm Length
MSRP: CA$ 536.25
In stock
SKU
PCD800B.1545.75
CA$ 536.25
Technical Specifications
| Tool ID | PCD800B.1545.75 |
|---|---|
| Brand | Dimar |
| Trade | Industrial |
| Diameter (D) | 15.87mm |
| Shank (d) | 15.87mm |
| Cutting Length (B) | 45mm |
| Overall Length (L) | 105mm |
| Axial° | 15-20° |
| Rotation | Right Hand (RH) |
| Number of Cutters | 10+1 |
| Teeth Thickness (H) | 2.5mm |
| Technology | PCD (Diamond) |
| Machine | CNC Machine |
| Material | MDF, Laminate, Plywood, Chipboards |
| Maximum RPM | 24,000 |
Description
Diamond polycrystalline router bits for pantograph, ideals for panels made on raw and coated chipboard, plywood, MDF, etc.
Positive/Negative axial construction, to get optimal finishing on both sides of the panel.
Capable of drilling thanks to the HM (Hard Metal) tooth. (On request, with PCD to drill) - Axial construction.
The axial angle changes with the diameter. (from 15 to 20 degrees)
It can be resharpened 2/3 times.
Right Hand Rotation.
Also available in Left Hand Rotation on request.
