PCD800B.12735.75
Industrial
12.7 mm Dia, PCD, Spiral Router Cutter, Z8+1, RH, 12.7 mm Shank, 85mm Length
MSRP: CA$ 429.00
In stock
SKU
PCD800B.12735.75
CA$ 429.00
Technical Specifications
| Tool ID | PCD800B.12735.75 |
|---|---|
| Brand | Dimar |
| Trade | Industrial |
| Diameter (D) | 12.7mm |
| Shank (d) | 12.7mm |
| Cutting Length (B) | 35mm |
| Overall Length (L) | 85mm |
| Axial° | 15-20° |
| Rotation | Right Hand (RH) |
| Number of Cutters | 8+1 |
| Teeth Thickness (H) | 2.5mm |
| Technology | PCD (Diamond) |
| Machine | CNC Machine |
| Material | MDF, Laminate, Plywood, Chipboards |
| Maximum RPM | 24,000 |
Description
Diamond polycrystalline router bits for pantograph, ideals for panels made on raw and coated chipboard, plywood, etc.
Capable of drilling thanks to the HM (Hard Metal) tooth. (On request, with PCD to drill) - Axial construction.
The axial angle of these tools changes with the diameter (from 15 to 20 degrees)
It can be resharpened 2/3 times.
Right Hand Rotation.
Also available in Left Hand Rotation on request.
