PCD800B.12725.75
Industrial
12.7 mm Dia, PCD, Spiral Router Cutter, Z6+1, RH, 12.7 mm Shank, 75mm Length
MSRP: CA$ 321.75
In stock
SKU
PCD800B.12725.75
CA$ 321.75
Technical Specifications
| Tool ID | PCD800B.12725.75 |
|---|---|
| Brand | Dimar |
| Trade | Industrial |
| Diameter (D) | 12.7mm |
| Shank (d) | 12.7mm |
| Cutting Length (B) | 25mm |
| Overall Length (L) | 75mm |
| Axial° | 15-20° |
| Rotation | Right Hand (RH) |
| Number of Cutters | 6+1 |
| Teeth Thickness (H) | 2.5mm |
| Technology | PCD (Diamond) |
| Machine | CNC Machine |
| Material | MDF, Laminate, Plywood, Chipboards |
| Maximum RPM | 24,000 |
Description
Diamond polycrystalline router bits for pantograph, ideals for panels made on raw and coated chipboard, plywood, MDF, etc.
Positive/Negative axial construction, to get optimal finishing on both sides of the panel.
Capable of drilling thanks to the HM (Hard Metal) tooth. (On request, with PCD to drill) - Axial construction.
The axial angle changes with the diameter. (from 15 to 20 degrees)
It can be resharpened 2/3 times.
Right Hand Rotation.
Also available in Left Hand Rotation on request.
