20-120-NF-32
Industrial
20" Dia, Carbide Tipped, Non Ferrous Saw Blade, .157" (4.0mm) Kerf, 120 Teeth, MTCG
MSRP: CA$ 665.66
In stock
SKU
20-120-NF-32
CA$ 665.66
Technical Specifications
| Tool ID | 20-120-NF-32 |
|---|---|
| Brand | Dimar |
| Trade | Industrial |
| Diameter | 20" |
| Teeth | 120 |
| Kerf (B) | .157” (4.0mm) |
| Bore | 32mm |
| Grind | MTCG- Modified Triple Chip Grind |
| Hook Angle | - 6° |
| Technology | Carbide Tipped |
| Material | Non-Ferrous Material |
| Machine | Panel Saw |
Description
For cutting aluminum sheets, tubing extrusions, and other nonferrous metals such as copper, brass, lead, and magnesium. For smooth cutting, use lots of lubricants and a clamping device.
Note: The material must be clamped firmly to the table on both sides during the cutting operation. The use of coolant is very important.
- Carbide tipped for maximum performance
- This blade is furnished with a Negative 6° hook angle for a reasonable finish
- This hook angle prevents self-feeding of materials and gives the operator maximum control over the feed of the cut
